Name: 6550 Rayos X Equipaje Escaner Maquina De Inspection De Equipaje De Mano Equipo De Seguridad Hospitalario Escolar Y Hotelario
Brand: Guangdong Maidun Security Equipment Co., Ltd.
Availability: InStock

Home Products Events Baggage Scanner

6550 Rayos X Equipaje Escaner Maquina De Inspection De Equipaje De Mano Equipo De Seguridad Hospitalario Escolar Y Hotelario

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	Maidun

Contact Now

Detailed Product Description

Type:	Baggage Scanner, Security Protection Products	Application:	Executive Offices, Hotels, Prisons, Public Places
Feature:	Durable	Tunnel Size:	659(L)*504(W) Mm
Conveyor Speed:	0.22m/s	Steel Penetration:	40mm Guaranteed
Wire Resolution:	AWG40	Penetration Resolution:	AWG32
Conveyor Max Load:	150kgs	Anode Voltage:	140KV
Operation Power:	220VAC(±10%) 50±3Hz (Options: 110-120V, 230-240V, 60Hz)	Power Consumption:	Max. 800W

Details Images

Product Paramenters

Gross weight	700kg
Unit size	2195(L)902(W)1363(H) mm
Noise	＜60dB
Power Consumption	max 800W
Operation Power	220VAC(±10%) 50±3Hz (Options: 110-120V, 230-240V, 60Hz)
X ray dose per each inspection	≤2.5μGy
Spatial resolution	Horizontal:dia 1.0mm, Vertical: dia 1.0mm
Operation temperature/Humidity	5℃-40℃ / 0%-90%(non-condensing)
Storage Temperature/Humidity	-20℃to 60℃ / 10%-90%(non-condensing)
Monitor	One 21.5-inch LCD monitor, 1920*1080, one console desk
Film Safety	Guarantee ASA/ISO 1600 Film
